Baileigh Industrial SR-5016M Slip Roll Machine
The SR-5016M slip roll has a forming width of 50" with a capacity of 16 gauge mild steel. This is a three roll machine with two driven rolls that are made of polished carbon steel offering years of reliable service. This is the perfect sheet metal tool to have in any HVAC shop or general fabrication shop when sheet metal forming is required. The frame is composed of two heavy solid steel frames that are electro-welded to a heavy base that allows for no deflection when bending across the entire useful width at full capacity (16 gauge mild steel sheet metal). This highly rigid construction will provide precision roll bending for many decades of production. This sheet metal roller comes standard with three wire or rod grooves. For rolling sheet metal simply place the unbent piece into the bender and bring the back roll up to the desired position, then start your bend. This sheet metal bender is easy to adjust and operate, making it simple to work with. Rigidity and simplicity define the SR-5016M roll bender.
MADE IN TAIWAN
Specifications:
- Forming Width | 50"
- Upper Roll Dia. | 3"
- Minimum Forming Dia | 4.5"
- Wire Grooves | Yes
- Stand | Optional
- Capacity (Mild Steel) | 16 ga. (.060")
- Gear Ratio | 3:1
- Power | Manual
- Shipping Weight | 642 lbs.
- Shipping Dimensions | 65" x 16" x 20"
*Specifications subject to change without notice.
